MV-90 15KV Medium Voltage Wire & Cable XLP, Shielded, 100% Insulation Level
Single Conductor Shielded XLP Insulation
PVC Jacket 100% Insulation Level
UL Type MV-90 15 Kv Power Wire & Cable Medium Voltage.
Application: As medium voltage MV-90 power cable for use in main feeder, distribution and branch circuits in industrial,
commercial and electric utility installations. Cables may be used in wet or dry locations in circuits not exceeding 15000 volts 100%
insulation level at conductor temperatures not exceeding 90°C for normal, 130°C for emergency overload and 250°C for short-circuit
conditions. Suitable for installation in conduit, trough, ducts, aerial and direct burial applications.
Standards: Conforms to ICEAS-93-639/NEMAWC74, ICEAS-97-682, AEICCS8, UL 1072 Listed as MV-90.
Construction: Annealed bare copper, class B per ASTMB-3, extruded conductor shield, XLP insulation, extruded insulation shield,
CU wire shield, tape, black PVC jacket, sunlight resistant.
MV-90 Medium Voltage Power Wire Cable 15kV Size AWG Gauge: 2 1 1/0 2/0 3/0 4/0 250 350 500 750 1000 MCM

DATA SHEET

mswcnewlogomed iStock_000009548141XSmall

DATA SHEET

DATA SHEET

MV-90 15KV Medium Voltage Wire & Cable
Single Conductor Shielded XLP Insulation
PVC Jacket 100% Insulation Level
UL Type MV-90 15 Kv Power Wire & Cable Medium Voltage.
Application: As medium voltage MV-90 power cable for use in main feeder, distribution and branch circuits in industrial,
commercial and electric utility installations. Cables may be used in wet or dry locations in circuits not exceeding 15000 volts 100%
insulation level at conductor temperatures not exceeding 90°C for normal, 130°C for emergency overload and 250°C for short-circuit
conditions. Suitable for installation in conduit, trough, ducts, aerial and direct burial applications.
Standards: Conforms to ICEAS-93-639/NEMAWC74, ICEAS-97-682, AEICCS8, UL 1072 Listed as MV-90.
Construction: Annealed bare copper, class B per ASTMB-3, extruded conductor shield, XLP insulation, extruded insulation shield,
CU wire shield, tape, black PVC jacket, sunlight resistant.
MV-90 Medium Voltage Power Wire Cable 15kV Size AWG Gauge: 2 1 1/0 2/0 3/0 4/0 250 350 500 750 1000 MCM
MV-90 15KV Medium Voltage Wire & Cable
Single Conductor Shielded XLP Insulation
PVC Jacket 100% Insulation Level
UL Type MV-90 15 Kv Power Wire & Cable Medium Voltage.

DATA SHEET
