15KV Medium Voltage MV-90 Wire
Cable
Single
Conductor Shielded XLP
Insulation
PVC Jacket
133% Insulation Level
UL Type
Wire Cable MV-90 Medium Voltage Wires Cables
133 Percent Insulation Level Wiring Cabling
MV-90 Medium Voltage Wire Cable 15kv 133% Sizes
AWG in
2 1 1/0 2/0 3/0 4/0 250 350 500 750 1000 MCM
15KV,
XLP, Shielded, MV-90,
133%
DATA SHEET
Medium Voltage MV-90 Wire Cable 15KV
133%
Insulation Level
Application:
As medium voltage MV-90 power cable for use in
main feeder,
distribution and branch circuits in
industrial, Commercial and Electric Utility
Installations.
Cables
may be used in wet
or
dry locations in circuits not
exceeding 15000
Volts
133% insulation level
at
conductor
temperatures not
exceeding 90°C for normal,
130°C for emergency overload and 250°C
for short-circuit conditions.
Suitable for installation in conduit,
trough,
ducts,
aerial
and direct
burial
applications.
Standards:
Conforms to ICEAS-93-639/NEMAWC74,
ICEAS-97-682, AEICCS8,
UL1072 Listed as MV-90.
Construction:
Annealed bare copper,
class B per ASTMB-3,
extruded conductor
shield,
XLP insulation,
extruded insulation shield,
CU wire shield,
tape,
black PVC jacket,
sunlight
resistant.
15kv
MV-90 Medium Voltage Wires Cables 15000 Volts,
Shielded, 133% Insulation Level Ungrounded
MV-90 Medium Voltage Wire Cable
15KV, XLP, Shielded, MV-90, 133%
DATA SHEET
DATA SHEET
15KV
Medium Voltage MV-90 Wire Cable
15KV, XLP, Shielded, MV-90, 133%
Single
Conductor Shielded XLP
Insulation
PVC
Jacket 133% Insulation Level
UL
Type Wire Cable MV-90 Medium Voltage Wires
Cables 133 Percent Insulation Level Wiring
Cabling
MV-90 Medium Voltage Wire Cable 15kv 133% Sizes
AWG in
2 1 1/0 2/0 3/0 4/0 250 350 500 750 1000
MCM
